APLS日本阿尔卑斯轻触开关主要手艺特征:
1. 情形温度Environment temperature: -25℃~+70℃
2. 相对湿度Relative Humidity: (40℃)≤95%
3. 额定规模Rating: DC12V.50mA
4. 接触电阻Contact Resistance : ≤0.03Ω
5. 绝缘电阻Insulation Resistance:≥ 100MΩ
6. 耐压强度Dielectric Strength : AC250V(50Hz for 1minute)
7. 电气寿命Electrically Life:100,000cycles
8. 行 程Travel:0.2±0.05mm
9. 操作力度Operating Force: 160±30gf
